Inner Tube
Oil-resistant NBR synthetic rubber, smooth bore. Compatible with petroleum-based hydraulic oils, fuel oil, lubricants, emulsions, glycol/water-glycol solutions and water.
SAE 100 R1AT / EN 853 1SN
RX-100
Single Wire Braid Hydraulic Hose
- 25.0 MPaMax. working pressure
- −40°C to +100°CTemperature range
- 3/16″ – 2″ · 11 sizesBore range
- StahlCore · SchützCoverConstruction system
Built to the standard it carries.
The RX-100 is Rexcron's general-purpose hydraulic hose for medium-pressure circuits in mobile machinery, industrial equipment, agricultural applications and general hydraulic service. The single-wire-braid construction allows a tighter minimum bend radius than spiral alternatives, making it the practical choice for confined routing spaces.
- SAE 100 R1AT / EN 853 1SN
- StahlCore™ · SchützCover™
- 3/16″ – 2″ · 11 sizes
StrengeTest verified · Burst tested to 4× working pressure
Three layers. One system.
Inside the RX-100.
StahlCore Reinforcement
StahlCore single high-tensile steel-wire braid — controlled wire grade, winding geometry and layer tension.
SchützCover Outer Layer
Oil- and weather-resistant synthetic rubber cover with resistance to abrasion, ozone, UV exposure and environmental stress.
Applications
- Mobile machinery
- Industrial equipment
- Agricultural applications
- General hydraulic service
- Confined routing spaces
Technical data
Size-by-size specification.
| Size (mm) | Size (inch) | ID min/max (mm) | OD min/max (mm) | Working Pressure (MPa) | Burst Pressure (MPa) | Min. Bend (mm) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|
| 5 | 3/16 | 4.6 / 5.4 | 11.1 / 13.0 | 25.0 | 100.0 | 85 | 0.20 |
| 6.3 | 1/4 | 6.2 / 7.0 | 12.7 / 14.0 | 22.5 | 90.0 | 100 | 0.25 |
| 8 | 5/16 | 7.7 / 8.5 | 14.3 / 16.0 | 21.5 | 86.0 | 115 | 0.31 |
| 10 | 3/8 | 9.3 / 10.1 | 16.7 / 18.0 | 18.0 | 72.0 | 130 | 0.36 |
| 12.5 | 1/2 | 12.3 / 13.5 | 19.8 / 21.0 | 16.0 | 64.0 | 180 | 0.45 |
| 16 | 5/8 | 15.5 / 16.7 | 22.9 / 25.0 | 13.0 | 52.0 | 200 | 0.52 |
| 19 | 3/4 | 18.6 / 19.8 | 26.9 / 29.0 | 10.5 | 42.0 | 240 | 0.65 |
| 25 | 1 | 25.0 / 26.4 | 34.6 / 37.0 | 8.8 | 35.2 | 300 | 0.91 |
| 31.5 | 1-1/4 | 31.4 / 33.0 | 42.2 / 45.0 | 6.3 | 25.2 | 420 | 1.30 |
| 38 | 1-1/2 | 37.7 / 39.3 | 49.1 / 52.0 | 5.0 | 20.0 | 500 | 1.70 |
| 51 | 2 | 50.4 / 52.0 | 62.5 / 66.0 | 4.0 | 16.0 | 630 | 2.00 |
Published values per SAE 100 R1AT / EN 853 1SN. Burst pressure ≥ 4× rated working pressure. Full tolerance and test detail in the controlled technical data sheet.
One system
Crimp it with Rexcron machines.
Hose and assembly equipment engineered to one standard — build the complete line around the RX-100.
